一輛配置6HP-19型自動變速器的奧迪A6L 3.0L轎車。該車在行駛中發生了2擋升3擋沖擊，4擋升5擋沖擊，6擋降5擋沖擊，4擋降3擋沖擊，掛倒擋也沖擊。

An Audi A6L 3.0L sedan equipped with a 6HP-19 automatic transmission. The car experienced impacts during driving, including shifting from 2nd gear to 3rd gear, shifting from 4th gear to 5th gear, shifting from 6th gear to 5th gear, shifting from 4th gear to 3rd gear, and shifting into reverse gear.

故障診斷：到奧迪服務站進行檢查，通過診斷儀診斷，自動變速器控制單元無故障碼，動態數據流也沒有異常。發動機控制系統檢測，顯示正常。所有車身電路用診斷儀檢測，顯示正常。在電路沒有故障的情況下，只有懷疑機械和油路兩個方面的問題。首先選擇更換閥體總成，路試后故障現象依舊沒有改變。提出更換自動變速器總成，車主覺得難以接受。于是到傳星自動變速箱進行維修。

Fault diagnosis: Go to the Audi service station for inspection. Through the diagnostic instrument, there are no fault codes for the automatic transmission control unit, and there are no abnormalities in the dynamic data flow. The engine control system has been detected and is displaying normally. All body circuits were tested with a diagnostic tool and the display was normal. In the absence of any faults in the circuit, only mechanical and hydraulic issues are suspected. Firstly, choose to replace the valve body assembly. After the road test, the fault phenomenon still did not change. The car owner finds it difficult to accept the proposal to replace the automatic transmission assembly. So I went to the Chuanxing automatic transmission for maintenance.

自動變速箱維修

Automatic transmission maintenance

根據車主提供的故障進行多方面的分析，暫時排除電路方面的故障。分析油路和機械兩個方面，查看6HP-19自動變速器元件工作表，結合車主提出的故障點進行分析。

Based on the faults provided by the car owner, conduct a comprehensive analysis and temporarily eliminate the faults in the circuit. Analyze the oil circuit and mechanical aspects, review the 6HP-19 automatic transmission component worksheet, and analyze the fault points raised by the car owner.

從機械元件工作表可以看出，2擋升3擋時B1制動器要泄油，K2離合器要供油，如果B1延遲泄油會發生沖擊，如果K2提前接合也會發生沖擊，兩種可能性其中存在一個。再分析4擋升5擋沖擊，是K1離合器要泄油，K2離合器要供油，在此出現第二次升擋沖擊又有K2參與，懷疑K2提前工作的可能性要大一點。再看6擋降5擋沖擊，是B1泄油，K2供油，在此又出現K2，懷疑K2提前接合的可能性更大。再看4擋降3擋沖擊，是K3泄油，又是K2供油。故障目標應該鎖定在K2離合器，但是還要分析引起K2離合器工作不正常的原因到底是在油路還是在機械方面?按照先易后難的方法，從油路方面分析，油路是受自動變速器控制單元控制的，如果自動變速器控制單元不提前控制工作，油路是不會自動提前供油的。也就是說，該車油路控制只會延遲不會提前(油路太臟會引起閥桿運動延遲)。把自動變速器拆卸分解，發現K2離合器活塞的錐形回位彈片斷裂。

From the mechanical components worksheet, it can be seen that when shifting from 2nd gear to 3rd gear, the B1 brake needs to drain oil and the K2 clutch needs to supply oil. If B1 delays draining oil, there will be an impact, and if K2 engages early, there will also be an impact. There is one of the two possibilities. Further analysis of the impact of shifting from 4th gear to 5th gear shows that the K1 clutch needs to drain oil and the K2 clutch needs to supply oil. In this case, there is a second upshift impact involving K2, and it is suspected that K2 may have started working earlier. Looking at the impact of shifting from 6th gear to 5th gear again, it is B1 leaking oil and K2 supplying oil. Here, K2 appears again, and it is suspected that K2 may have engaged earlier. Looking at the impact of downshifting from 4th gear to 3rd gear, it's K3 leaking oil and K2 supplying oil. The fault target should be locked in the K2 clutch, but it is also necessary to analyze whether the cause of the abnormal operation of the K2 clutch is in the oil circuit or in the mechanical aspect? According to the method of "easy first, difficult later", from the perspective of oil circuit analysis, the oil circuit is controlled by the automatic transmission control unit. If the automatic transmission control unit does not control the work in advance, the oil circuit will not automatically supply oil in advance. That is to say, the oil circuit control of the vehicle will only delay and not advance (too dirty an oil circuit can cause a delay in valve stem movement). Disassembling the automatic transmission revealed that the conical return spring of the K2 clutch piston was broken.

由于錐形回位彈片斷裂，兩塊固定錐形彈片的卡片都掉在兩邊。由于K2離合器活塞泄油時沒有彈片幫助活塞回位，K2離合器摩擦片就沒有間隙，潤滑油進不到K2離合器摩擦片表面，摩擦片干摩擦后燒片。又由于K2離合器片沒有間隙，供油時K2離合器馬上就接合;沒有緩沖，造成升擋降擋都沖擊，掛倒擋時也有沖擊。故障目標確定，隨進行更換，完成后反復試車，故障排除。

Due to the breakage of the conical return spring, two cards that fix the conical spring fell on both sides. Due to the lack of spring plates to help the piston return to its original position when the K2 clutch piston leaks oil, there is no clearance between the K2 clutch friction plates, and lubricating oil cannot enter the surface of the K2 clutch friction plates. The friction plates dry and burn after friction. Due to the lack of clearance between the K2 clutch plates, the K2 clutch immediately engages when supplying oil; There is no buffer, causing impact when shifting up or down, and also when shifting in reverse. Identify the target of the fault, replace it immediately, and conduct repeated testing after completion to eliminate the fault.
