1. Mild water ingress: some screws in the gearbox are rusty

如果用以上兩種做法都無法判斷，則需要通過拆解觀察變速箱里面的螺絲。因為油和水混合之后，會腐蝕鋼性材質的螺絲，如果變速箱疑似進水以后發現有部分螺絲生銹，則可以判斷是變速箱輕度進水，且含水量不會太大。

If the above two methods are unable to judge, it is necessary to observe the screws inside the gearbox by dismantling. Because the mixture of oil and water will corrode the screws made of steel material. If the gearbox is suspected of water ingress and some screws are found to be rusty, it can be judged that the gearbox is slightly watered and the water content is not too large.

維修方式：

Maintenance mode:

更換變速箱油和差速油。輕微進水的維修辦法與中度進水類似，但主要是以預防為主。更換膠圈、油封、摩擦片等部件，以延長使用壽命，并建議更換變速箱油和差速油。自動變速箱專修

Change the transmission oil and differential oil. The maintenance method of slight water inflow is similar to that of moderate water inflow, but the main method is prevention. The rubber ring, oil seal, friction plate and other parts should be replaced to prolong the service life. It is suggested to replace the transmission oil and differential oil. Special repair of automatic transmission

2、中度進水：油底殼出現白色沉淀物

2. Moderate water inflow: white sediment appears in the oil pan

如果通過放油無法確定是否進水，這時候需要做進一步的檢查。具體做法是把油底殼拆卸下來進行觀察。因為如果變速箱進水，油和水混合之后會產生一種白色的乳合物，并附著在油底殼上，如果觀察到有這種沉淀物，那么變速箱就已經屬于中度進水。

If it is impossible to determine whether there is water inflow through oil drainage, further inspection is required at this time. The specific method is to remove the oil pan for observation. Because if there is water in the gearbox, the mixture of oil and water will produce a white emulsion compound, which will adhere to the oil pan. If this kind of sediment is observed, the gearbox is already in the category of moderate water inflow.

維修方式：摩擦片、油封等部件必須更換。中度進水比嚴重進水需要更換的部件要少很多，但是膠圈、油封、摩擦片等部件，以及變速箱油和差速油都必須徹底更換。如果自動擋多功能開關等元件涉水也需要更換。

Maintenance method: friction plate, oil seal and other parts must be replaced. Moderate water inflow is much less than severe water inflow, but rubber ring, oil seal, friction plate and other components, as well as transmission oil and differential oil must be completely replaced. If the automatic multi-function switch and other components wade in water, they also need to be replaced.

Jinan automatic transmission maintenance

3、嚴重進水：觀察油水混合物即可辨別

3. Serious water inflow: it can be identified by observing the oil-water mixture

變速箱進水比較嚴重的，可以通過放油直接觀察。具體做法是把變速箱里的油排出來，如果進水較多觀察油水混合物的顏色和黏稠程度就能判斷。

If the water in the gearbox is serious, it can be observed directly by draining the oil. The specific method is to drain the oil in the gearbox. If there is more water in, the color and viscosity of the oil-water mixture can be judged.

維修方式：至少三項需要更換。

Maintenance method: at least three items need to be replaced.

(1)要更換膠圈、油封一類的橡膠性質的元件;

(1) To replace rubber ring, oil seal and other rubber components;

(2)要更換摩擦片，因為摩擦片由鋼片和高密度的木脂材料組成，遇水發脹后會影響摩擦效果;

(2) It is necessary to replace the friction plate, because the friction plate is composed of steel plate and high-density wood grease material, which will affect the friction effect after swelling in water;

(3)還需要徹底更換變速箱油和差速油;

(3) The transmission oil and differential oil need to be completely replaced;

(4)進水嚴重時需要更換鏈輪;

(4) The sprocket wheel needs to be replaced in case of serious water inflow;

(5)是否更換變速箱的閥體要視情況而定，因為如果變速箱進水潤滑效果就會減弱;

(5) Whether or not to replace the valve body of the gearbox depends on the situation, because if the gearbox is filled with water, the lubrication effect will be weakened;

(6)如果自動擋多功能開關等元件涉水也必須更換。濟南自動變速箱維修

(6) If the automatic multi-function switch and other components wade in water, they must also be replaced. Jinan automatic transmission maintenance
